Product Description

Kubota SQ1150 Four Pole Fully Sound Attenuated Single Phase Diesel Generator.

The SQ Series of diesel generators provides a much quieter, more efficient and longer service life machine, for applications where you need safe and economical electrical power.kubota-logo

  • Cleaner Power: The 03 and V3300 series of engines used in the SQ series incorporates the TVCS combustion system which improves air/fuel mixture, resulting in cleaner emissions
  • Dependable Power: The brushless, self-excited type alternator is designed to deliver high quality power
  • Quieter Power: Sound levels at full load and no load are minimised due to world renowned Kubota technology including quieter cooling fans, second mufflers and noise absorbing ducts within the cabinets
  • Increased Safety: The engine is protected against any abnormalities within the oil or cooling systems, and all rotating parts are enclosed in a sturdy lockable enclosure
  • Simple Maintenance: Oil, water and filters are located on one side of the machine for ease of maintenance
  • Ease of Transport: Centre-lifting lugs and forklift slots ensure that the transport of the SQ series is kept as easy as possible

SPECIFICATIONS
Set
Fuel Diesel
Fuel Tank Cap 62 L
Operating hrs 9.7 @ Full Load
Start System Electric
Weight 730kgs
Sound Levels 63dBA @ 7m
Dimensions 1675mm x 780mm x 970mm
Engine
Model V2203-EBG
Type Vertical Water Cooled Diesel Engine
Displacement 2197cc
Cylinders 4
Bore & Stroke 87mm x 92.4mm
Rated Output 18.4kW @ 1500rpm
Alternator
Type Revolving Field
Max Output 16.0kVA (16.0kW)
Rated Output 15.0kVA (15.0kW)
Voltage 240
Frequency 50Hz
Current 62.5Amps
Power Factor 1
Poles 4
Voltage Regulation AVR
