Product Description

Genelite is the exclusive distributor of Chicago Pneumatic compressors in Australia.

The Chicago Pneumatic CPS 275 – CPS400 are a direct-drive oil-injected rotary screw type of air compressor, powered by a water-cooled Cummins diesel engine. The unit consists of an element, diesel engine, cooling, air/oil separation and control systems – all enclosed within a sound-dampened strong canopy. Special attention has been given to the overall product quality, user friendliness, ease of serviceability, and economical operation to ensure best in class cost of ownership.

Note: This unit comes into Australia without an undercarriage. If you would like an undercarriage, we can make one here is Australia for an additional charge. Contact us for more info.

Features

  • Reputable engine brand
  • Efficient screw element
  • Efficient air/fuel filtration
  • Galvanized powder-coated canopy
  • User-friendly instrument panel
  • Low noise level
  • Robust single axle undercarriage

Benefits

  • World-wide support, high up-time
  • Efficiency, low cost of ownership
  • Protection from engine damage, low cost of ownership
  • Robust, impact-resistant, all guaranteeing a higher resale value
  • Ease of operation, protected from operators’ fault
  • Able to work in noise sensitive areas
  • Low transportation costs

Freight charges vary depending on your location. Please contact Genelite for a quote for shipping.



Type CPS350-12 Cu
Performance
Normal effective working pressure bar 12
Actual free air delivery m3/min 10.4
Max. sound power level (Lw) dB(A) 104
Max. sound pressure level at 7 m (Lp) dB(A) 77.9
Max. ambient temperature °C 50
Max. ambient temperature with aftercooler °C 50
Air compressor outlets 1 x 1”+ 3 x G3/4”
Min. starting temperature (with cold start equipment) °C -10 (-25)
Compressor
Compressor type Screw
Number of stages 1
Oil capacity L 20
Engine
Cummins 4BTA3.9-C130
Number of cylinders 4
Output at rated speed kWt 97
Swept volume L 3.9
Engine speed (nominal) rpm 2300
Engine speed (unloaded) rpm 1430
Capacity oil system L 9
Capacity of fuel tank L 185
Fuel consumption at 100% load kg/h 21.5
Speed regulation Mechanical
Electrical system V 24
